Mono Solar Panel 550W

Product model:

Product classification:

Solar Panel

E-mail:

leo_zecrowntech@163.com

Hotline:

+86-13599218143

Related products

Product message

Detailed information

Mono solar panels solar modules 550W with 182mm half solar cells for solar system

Solar Mono 550W adopts the PERC process, offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on the energy generation, lower risk of hot spot, as well as enhanced tolerance for mechanical loading.

Model:

JMD550P-144M

Size:

2279*1134*35mm

Cell range:

6*24 (182*91mm)

Weight:

27.3 kg/pc

Packing:

31 pcs/pallet 40HQ loading 620 pcs, 20 pallets

Our solar panels have the following characteristics

● Efficient 182 cells: Better current collection capacity, larger power generation area, beautiful appearance, more suitable for roof installation.

● High output power: Adopting PERC cell structure technology (low resistance characteristic), mono module has a maximum output power of 600W (module conversion efficiency up to 22%).

● Low light performance: By using excellent surface velvet technology for glass and battery cells, excellent performance can be achieved in low light environments.

● Adaptability to harsh environments: Certified for high salt spray and high ammonia corrosion testing, capable of adapting to harsh and complex environments.

● Solar cell: We use well-known brand and high efficieny A grade PV cells, with consistent appearance on each module, Anti-PID.

● Glass: With tempered and anti-reflective glass, module efficiency is increased by 2%, easy cleaning function, and service life as long as 25 years.

● Aluminium frame: Silver or black frame are optional, boost bearing capability and prolong service life.

● Junction box: IP67 protectional level, quality diode ensures module running safety, and excellent heat dissipation.

Keyword:
